Putting the Waxes into Moulds

river project, Work in Progress

This slideshow requires JavaScript.

These photos show the process of prepping my wax bones for the kiln.
Process:

  • I started by pressing the waxes into clay, separated by a layer of cling film to make it easier to remove the clay at a later stage. I built up the clay a little to help hold the waxes in place
  • I then joined the waxes to create runners (where the metal would flow through) and risers (where the metal rises out of) using wax tubes, straws, and sausages of soft wax, depending on the thickness of each bone. I added additional runners made of soft wax to any points on the bone that were smaller, thinner, or looked like they would benefit from it and joined them onto thicker parts of the bones or onto the main runners
  • Once I was happy with how the runners and risers and I had degreased them with meths (to help the grog stick) I then began to layer up the first coat grog mix (2:1 grog and herculite) starting off with a paintbrush to work it into the details of the bones. As the mixture thickened I then pressed it on and built it up around the waxes, making sure not to cover the main runners and risers (the pieces you can see sticking out)
  • When the grog had been built up enough and left to dry I then flipped them over, removing the clay and cling film, so that I could repeat the process of layering up the first coat grog
  • I then needed to extend the runners and risers further, bringing the risers at the bottom up to the top, layering with more grog as I went along, for support
  • As I did this Becky built up a base with grog, which we then used to stand up the separate parts of the mould, building the grog round the sides until it was stable
  • Next we had to get the cup onto the runners, using hot knives to join them and soft wax for additional support
  • Because of the heat we had to degrease and add more grog around the runners for support as we went, as we left one over night only to find that the wax had curved over in the heat
  • I then extended the runners using hot knives to join the pieces of wax tube, and bring them up to the top of the cup, again degreasing and layering grog as I went for support
  • The next stage was to fit a sheet of plastic around the whole thing, which we secured with duct tape, before mixing a batch of normal fine casting plaster. We then dipped some scrim into the plaster and used this to secure the plastic to the base- working extra plaster in to waterproof the join. We also tied some plaster dipped scrim around the middle of each mould to help stabilise it ready for the 2nd coat grog to go in
  • This isn’t shown in the photos but we then filled the mould gradually with 2nd coat grog (1:1:1 grog, ludo and plaster then 2:1 ludo and plaster) until it was to the top of the cup and left it to set

We made 3 moulds this way with the wax bones inside, but I will be uploading a more in-depth video showing the process of the two wax brick moulds once I have finished editing it!

Casting the Jawbone

Photographs, river project, Work in Progress

This slideshow requires JavaScript.

Casting the jawbone raised a host of issues that I didn’t realise would be a problem, but hopefully it will work out in the end. Before we could make a hot rubber mould of the jawbone Becky (the technician) and I decided to make a plaster cast of the jaw, as we felt it would be too fragile to make a hot rubber mould from directly.

STEPS

  1. Before we could begin casting I had to fill in the holes in the jaw (where the rest of the teeth originally were) with soft wax, so that it would be easier to cast. I also used a little superglue to secure the two teeth- we were worried that they may have come out of the jaw when we de-moulded it, so this was a preventative measure.
  2. I then pressed the jaw carefully into some clay and built up clay walls around it, and then applied a few layers of vegetable oil to the jaw to help release it from the mould once the alginate had set
  3. I mixed up a small amount of quick set alginate which I poured into the clay mould and left to set
  4. Once this had set I carefully removed the clay and rinsed the jaw and alginate, before greasing it up with more oil, and building up clay walls around it
  5. Another batch of quick set alginate was then poured over this, and left to set
  6. The clay was then removed, and the two halves of the mould separated and the jaw carefully removed.
  7. After cleaning both halves of the mould I fit them together and secured them with elastic bands, and was then ready to pour fine casting plaster into it
  8. The first attempt didn’t work very well and only the thickest section of the jaw came out, so for the second attempt after pouring in the plaster I moved the mould around to encourage the plaster to flow through the whole mould
  9. Once I opened the mould up I realised one half had not worked out, and the other half, where all the detail was, was too thin- to fix this I cut up scrim and layered that and some more plaster on top of it until it was thicker and stronger
  10. I then de-moulded it and created a hot rubber mould from that plaster cast. Because the detail was lost on one side I decided to make a flat mould, rather than a round one that needed to be cut open, to save materials
  11. The final photo on the slideshow is of the original jaw, first failed plaster cast, second plaster cast, and de-moulded wax cast of the jaw- as you can see there are a lot of details that need to be worked back into the wax by hand, but I am confident that it is doable

Wax Casts

Photographs, river project, Videos, Work in Progress

This slideshow requires JavaScript.

Photos of the wax casting process- melting the wax in a saucepan before leaving it to cool to pouring temperature (the wax needs to be cool enough that it coats the side of the pan), then pouring into the secured moulds, including the larger brick mould, before de-moulding and removing excess wax/working the details back in.

Video of two wax casts, fresh from the mould- you can see that there is excess wax that needs to be removed, and some of the details need to be worked back in to the casts.

Video made up of a clip showing the second, larger batch, of wax casts fresh from the moulds, followed by a clip of me working on one of these casts to remove excess wax and work a hole back into the cast to mimic the original bone. The final photo is of the wax cast from the previous clip next to the original bone I cast it from- you can see that I have worked some of the details lost during the hot rubber mould process back into the wax cast.

The two clips in this video show the first hollow wax cast of the brick I found on the river, and the second cast next to the original brick- you can see how the hot rubber mould picked up most of the detail from the brick, and how that has translated to the wax casts. You might notice some lines on the casts- this is because to make a hollow cast you need to pour in the wax slowly and roll the mould gently around to ensure the wax coats the mould properly- I did this too slowly so there are lines visible. Next time I use the mould I will be careful to pour the wax faster to avoid this happening- I may melt these two casts down and redo them.  The brick casts need to be hollow as to make a solid bronze of that size would be too costly, and too heavy. I will either have to leave the hole in the bottom, or weld a small piece of metal over the hole, but this is something I will tackle when I get to that stage.

Unfortunately this was all I was able to get done before the workshops closed for the break, but I am looking forward to getting back into the foundry/plaster room and continuing my work! The plan is to make at least two of each bone in wax, and then make at 2 – 4 large moulds to go into the kiln and then be poured, as I want a copy of each bone in aluminium and in bronze. I have also been shown a material called glass wax, which is used in the film industry to make objects that mimic glass, and if  I can afford it I would like to experiment with this medium as well, as it will give me another material and colour to analyse.

Hot Rubber Moulds

river project, Work in Progress



This slideshow requires JavaScript.

Whilst working on the burn out moulds that didn’t work I also decided to make a few batches of hot rubber moulds. The process is lengthier, but once the final plaster mould is fired in the kiln the waxes will melt out leaving hollow spaces for the molten metal to be poured into.

To start the rubber needs to be melted in the machine, by being fed into the top, and the press placed on top of it, using gravity to push it down to melt. It then drips out of the bottom into a bucket to be poured. Whilst it is melting I prepared the objects, by applying vegetable oil to each object for easier release from the moulds, then embedding them into clay, creating tunnels with the clay for objects that were going to be solid (although for the brick shown in the photos this was not necessary as I wanted it to be hollow and this required one side to pour in the wax). I then made a tube out of metal or plastic secured with duct tape, and pressed it into the clay bases around the objects. The tube then needed to be waterproofed with extra clay, ready for the melted rubber to be poured in. The next step was to pour the hot rubber into the moulds, and leave it to set. Once it was set I then made a basic plaster mix and poured this into the leftover space in the moulds of the bones (not the brick) to create a flat base for them to rest on.

When the plaster had set I then removed the metal/plastic tube and the clay from the moulds, and flipped them the right way up, using a craft knife as shown to make a few cuts into each mould, to allow me to remove the objects from the moulds. Once this was done they needed to be thoroughly washed to remove clay residue, and then secured with elastic bands or duct tape ready to pour the wax into.

Unknown Landscapes/ Impromptu Pop up Show

Exhibitions, Photographs, river project, Videos

The above video is of my “Unknown Landscapes” piece in the end of term pop up exhibition ‘Impromptu’ held in uni, with work from both first and second year students. I wasn’t involved in the set up of the exhibition so I had no idea the video works would be displayed like this, with each screen slightly delayed from the previous screen to create this effect- but I really like it and think it is really effective in showing off my work!

This slideshow requires JavaScript.

The images show my work at different stages on the screens, as well as shots of my classmates’ work. The exhibition was small but well curated and I feel that all the pieces worked well together in the space, despite being very different.

Foundry Work: Burn out

river project, Videos, Work in Progress

This slideshow requires JavaScript.

I haven’t updated in a while, as I have been busy physically making work in the foundry this term, which takes up a lot of my physical and mental energy- it is a very hands on, time consuming process, and at the time of writing this I have no finished pieces, as my first mould did not work.

The photos above show the process of making the mould.

  1. The bones were first pressed into clay, which then had plaster poured over the top of it. This photo shows the second stage, where the clay has been removed and cleaned away, to reveal the bones embedded into the plaster
  2. The next stage was to join each of the bones together with soft wax sausages, moulded by hand- this would later become the channels that the metal ran through
  3. The soft wax sausages then needed larger hard wax tubes attached, using hot knives heated over a Bunsen burner to melt and attach them- the top tubes would become channels for the hot metal to run through, and the bottom ones were for ventilation. The wax and bones then needed to be de-greased so that the grog (a special mix of plaster) would stick to it
  4. I then began layering on the grog, carefully over the wax and bones, so as not to damage or dislodge them, extending the wax tubes at the top of the mould as I did so
  5. This photo shows the additional wax tubes added as I applied grog- the joins on the wax tubes were wrapped with the soft wax to strengthen them
  6. Another stage in the grog process
  7. At this point the mould was stood upright, using more grog, onto the board I was working on, and the wax tubes further extended
  8. Once it was upright I then needed to build soft wax around a paper cup, to create the funnel for the top of the mold, which was then attached to the wax tubes. I added more grog as I went along for support, as the wax tubes were very fragile, and the cup was heavy from the added wax
  9. I then made a cylinder out of plastic using plastic sheeting and duct tape, to fit around the mould. To keep it in place I used fabric dipped in plaster to create a band around the middle of the mould, about halfway up (for support) and more of the fabric dipped in plaster around the bottom (to seal the plastic to the board)
  10. The next stage was to make the second coat grog mix (it is made with ludo instead of fine casting plaster) and carefully fill the cylinder to the top with this mix. This had to be done slowly, in stages, to prevent the heavy mixture from damaging the rest of the mould, and also to make sure it was completely filled.
  11. Once it was set Becky (the technician) removed the plastic layer, and covered the outside in fabric dipped in plaster to make a sturdy outer layer, and the mould was then fired in the kiln at a very high temperature to melt the wax and burn out the bone fragments. This photo shows the mould once it had been filled with molten bronze and left to set

The video above shows the pouring process in the foundry, done by Becky and another technician. My mould is the middle one!

12. This photo shows Becky removing the outer layer from my mould
13. We then began to smash my mould open (carefully) to see if it had worked
14. This photo shows the broken mould- you can see the metal has filled the cup and the top of the wax channels, but stops at the bones
15. The fragments of bone in my hand- this mould failed as the kiln did not get hot enough to burn the bones out, meaning the metal had nowhere to go.

I was very disappointed that this mould failed, but it was an experiment, and myself and Becky realised that the kiln was not going to be able to reach the kind of temperature we needed without it breaking my mould. This mould took me nearly two months to complete, as I had to wait between each step to check with Becky that I was doing it right, and to ask what the next stage was, as it was my first time doing this, but I am already halfway on the shell mould. This is because once you know what you are doing it is much easier to just get on and do it, which I will continue to do! Also I have only been in the foundry 3 days a week, as Wednesdays it shuts at 12.30 and I struggle to get in early enough, and Fridays it is shut. Going forwards I plan to finish the shell burn out mould (hopefully it will work) and also continue making wax versions of some of my bigger bones, to make into a mould. My next post will show the process of making a hot rubber mould, and waxes from that!

Low Residency- one day monoprinting workshop

river project, Work in Progress

This slideshow requires JavaScript.

A one day monoprinting workshop during the Low Residency.
The photos above show the process of monoprinting- I started off with some large print outs of a few of the macro photos I took of the bones, and inked up a plate with a roller. To make the prints I put a sheet of paper down onto the inked up plate, with one of the print outs on top of that. I then carefully drew over the photo with a pencil, applying harder pressure to create a darker mark, and lighter pressure for lighter marks and shading. Unfortunately the first few attempts didn’t work so well, as the paper I had chosen to print on was too thick, so not a lot of the lighter details were picked up. I then experimented with different mark making techniques on the thick paper and also on newsprint, until I was happy.

The smaller print and ghost print* (rectangular shaped) were made by soaking the thicker paper in water and then making the prints, but due to the amount of detail I was trying to capture the paper dried before I finished the print, meaning it didn’t come out as well as I was hoping. I ran the plate through the press with the second soaked sheet any way, to make the ghost print (black print with white lines).

To make the larger, better print, and the ghost print made from that, I used newsprint, as it didn’t need to be soaked, and picked up even the lighter marks made on the paper. I spent about an hour and half on this print as I really wanted to capture all of the tiny details from the photograph, and overall I am pleased with how this came out! I then ran the plate through the press with a second sheet to get the ghost print. One of the issues with newsprint is how fragile it is, and also that it discolours over time, but this could work in my favour, as the gradual transition of the paper will mimic how bones discolour over time with age, which is quite beautiful.

For a one day project I am very pleased with how the prints came out, and I had fun with the process. I think based on these outcomes that the macro photos would look very beautiful if I photo etched them, so this is something I may consider doing in the future.

* a ghost print is a print made from the negative of the original print- in this case when you remove the sheet of paper from the inked up plate wherever you have made a mark the ink will have transferred to the paper, giving you a positive print. To make a negative you then run the plate through the press with another sheet of paper, and this gives you a negative or ‘ghost’ print.

Unknown Landscapes

river project, Videos, Work in Progress



Shot with a macro lens on a DSLR camera, closeups of bones found along the river, using a moving light source to illuminate the bones. If anyone would like to create some sound to go with this video then please contact me! I have little experience in sound art and music, and would love to have some accompanying sound.

I am actually very pleased with how this work turned out, as it was only my second time using a macro lens, and I feel I captured the beauty and detail in the bones perfectly through this medium. For such a simple experiment I think I have created one of my favourite pieces of work, and I would like to explore this further in the future. My only regret is that currently the video has no sound, and I feel it could be greatly enhanced by it. I might go back to the spots where I found the bones along the river and record some of the sounds- I could then layer these sounds with the video and play around with it.

WIP- White: The Gallery Space, and the Classism and Racism of the Art World

Research for River Project (White), river project, Work in Progress
  • Discuss my own work- why I chose white, and how the audience’s perceptions would be different if I had presented the original objects in the gallery space (photos of my work in the gallery space
  • Rachel Whiteread’s use of white concrete and other white materials in her work (photos from the Tate Britain retrospective)
  • ‘The Whiteness of the Whale; Moby Dick’ discuss this chapter and quote how it describes white:
    -‘In many natural objects, whiteness refiningly enhances beauty, as if imparting some special virtue of its own’
    -‘This same hue is made the emblem of many touching, noble things- the innocence of brides, the benignity of age’
    -Native Americans are described as “Red Men of America” – this is an old work of fiction, and is impacted by the racism of the time
    -He also acknowledges that white has negative connotations- ‘Witness the white bear of the poles, and the white shark of the tropics; what but their smooth, flaky whiteness makes them the transcendent horrors they are? That ghastly whiteness it is which imparts such an abhorrent mildness, even more loathsome than terrific’
    -‘The common, hereditary experience of all mankind fail to bear witness to the supernaturalism of this hue. It cannot be well doubted, that the one visible quality in the aspect of the dead which most appals the gazer, is the marble pallor lingering there’ – white has a deep link to death
    -‘Or is it that as in essence whiteness is not so much a colour as the visible absence of colour, and at the same time the concrete of all colours’
  • Adolf Loos- ‘Ornament and Crime’
    -The racism- comparing Papua New Guinean tribes to children and criminals, and later ‘Are we alone, the people of the nineteenth century, supposed to be unable to do what any Negroe. All the races and periods before us have been able to do?’ (Speaking of the apparent realization that the people (meaning white people) of the nineteenth century found themselves unable to produce ornamental designs. (The lecture was originally given in 1908)
    -‘The evolution of culture is synonymous with the removal of ornament from utilitarian objects.’ The idea that plain things are better definitely arose during the industrial revolution- everyone needed things faster, and objects with no ornament could be produced even more quickly. But he also talks of ‘peasants’ ‘in the country’ as holding on to objects of past centuries, I would argue because they cannot afford new things- he shows disdain for lower classes as well as people of colour
    -‘We have art, which has taken the place of ornament. After the toils and troubles of the day we go to Beethoven or to Tristan. This my shoemaker cannot do. I mustn’t deprive him of his joy, since I have nothing else to put in its place.’ Here we see him discussing his shoemaker, and how the shoemakers’ only joy comes from ornamenting his shoes with decorative patterns- it is incredibly patronising to the working class, as he is stating that they cannot enjoy art, they can only derive enjoyment from the job they perform for the upper class
    -‘Absence of ornament has brought the other arts to unsuspected heights’
    -‘Freedom from ornament is a sign of spiritual strength. Modern man uses the ornaments of earlier or alien cultures as he sees fit. He concentrates his own inventiveness on other things’

‘Hybrid.’ Work in Progress Exhibition

Exhibitions, Photographs, river project

This slideshow requires JavaScript.

‘Hybrid.’ was our first exhibition on the course, and it opened on Friday 1st December for one week at the Two Girls Cafe in Peckham, consisting of work from both first and second year of MA Fine Art Digital.

I worked very hard to get my work finished for the exhibition- it took a lot of testing to get the moulds exactly the way I wanted them, and there were still small things I couldn’t fix. For example, most of the plastic bottle is still trapped inside the mould, as the heat compressed it too much and although I tried to cut the bottle out of the mould I was only partly successful- this was something I had to live with as it was not visible from the side on display and any further cutting would have damaged the piece beyond repair. As it was both the brick and wood casts had a few small tears in the plastic, but I positioned the pieces on the wall so that they were not visible, and as the wall was white I think the tears went unnoticed. Plastic can be a very unforgiving medium, so overall I am pleased with how my moulds turned out- the rope mould in particular captured a lot of detail and was visually very pleasing. Also regarding the presentation I did not use a tape measure or a spirit level, which would have made my pieces look much more professional, so these are two pieces of equipment I plan on investing in for future exhibitions, to avoid my work looking amateurish. Due to the nature of how the hot plastic warped and bent it was very difficult to cut the pieces neatly and to the same size- I used the laser cutter, but also had to use a ruler and scalpel to cut some of the parts that were too curved. As a result each piece was a slightly different size and shape, as it was impossible to get them perfect which was frustrating, but something I had to live with. The pieces did for the most part sit well against the wall once nailed in place though, which I was pleased about.

I definitely need to be more involved with the class moving forwards, as I did not have much input into the exhibition, beyond my own work, and I feel I let myself and the class down because of this. I hope to rectify this coming back for term 2 in January by being more proactive, and attending as many lectures and tutorials as I am able, so that I can fully engage with my peers and the topics we cover.

I think the work I put into Hybrid is the very definition of work in progress- it represents a turning point in my thinking, and is indicative of the struggles I have experienced in the last few months- it was not perfect or as polished as I would have liked, but I am very proud of myself for persevering and finishing the pieces in time for the exhibition. Going forwards I definitely want to try recreating more of my found objects in other mediums, such as ceramics, plaster, metal, and resin, to explore how the objects change and take on a new medium in other media and colours. I originally planned this project to be purely focused on making and processes, but seeing my work on the wall of the gallery space made me question why I chose the colour white, and why it is so overused in the art world. This has led me to a new topic for research- How and why is white used in the art world, and does it link to the inherent classism and racism that dominates the art world?
